Ford 771 Overview
The Ford 771 is listed from 1958 through 1962 with 134 cu in (2.2 L) and 144 cu in (2.4 L) engine listings, a Select-O-Speed full power-shift transmission, live 540-rpm rear PTO, open-center hydraulics, and a Category I rear hitch. An individual tractor still needs to be identified by its tag and engine before a part or procedure is treated as a match.
The serial-number plate is listed on the left side behind the starter, on top of the transmission case. Record that number together with the engine, transmission, PTO equipment, and electrical system before buying parts or opening a service manual.
The service and parts routes below are literature-access references. Their stated applications are broader than a single tractor configuration, so the serial number and the actual machine remain the fitment check.
Ford 771 Quick Answers
- When was the Ford 771 built?The Ford 771 is listed from 1958 through 1962. Use the serial-number rows and the full identification tag to narrow down an individual tractor.
- What engine is listed for a Ford 771?Published Ford 771 engine records list 134 cu in (2.2 L) and 144 cu in (2.4 L) engine options. Confirm the engine on the tractor before choosing engine parts or a service procedure.
- What transmission does the Ford 771 use?The Ford 771 is listed with a Ford Select-O-Speed full power-shift transmission with ten forward and two reverse gears. Verify the fitted transmission before using a capacity or parts reference.
- Does the Ford 771 have live PTO?Published specifications list a live 540-rpm rear PTO. Confirm the installed PTO equipment and controls before implement setup or diagnosis.
- What capacities are listed?Published records list 13 gal (49.2 L) of fuel, 2 gal (7.6 L) for the hydraulic system, 5 qt (4.7 L) of engine oil, and 15 qt (14.2 L) of coolant. Use matching literature for fluid grades, fill procedures, and intervals.
- Where is the Ford 771 serial number?The serial number is listed on the left side behind the starter and on top of the transmission case. Photograph the complete tag before ordering parts or comparing a serial row.
Engine and Power
Published Ford 771 records list 134 cu in (2.2 L) and 144 cu in (2.4 L) engine options. Confirm the engine before applying a capacity, a setting, or a manual route to a particular tractor.
Gasoline engine
| Displacement | 134 ci 2.2 L |
|---|---|
| Compression | 7.5:1 |
| Rated Rpm | 2200 |
| Starter Volts | 6 |
| Coolant Capacity | 15 qts 14.2 L |
LP-gas engine
| Displacement | 134 ci 2.2 L |
|---|---|
| Rated Rpm | 2200 |
| Starter Volts | 6 |
Diesel engine
| Displacement | 144 ci 2.4 L |
|---|---|
| Rated Rpm | 2200 |
| Starter Volts | 12 |
Manufacturer
Manufacture years
Transmission
The Ford 771 is listed with the Select-O-Speed full power-shift transmission and ten forward, two reverse gears. Match the actual transmission before ordering parts or relying on a service procedure.
Ford Select-O-Speed
| Name | Ford Select-O-Speed |
|---|---|
| Type | full power shift |
| Gears | 10 forward and 2 reverse |
PTO and Hitch
Published specifications list a live 540-rpm rear PTO and Category I hitch. Confirm the PTO equipment and hitch arrangement before setting up an implement.
Rear PTO
Rear PTO type
Rear hitch
Rear lift
Hydraulics
Published data lists open-center hydraulics with a 2 gal (7.6 L) system capacity. A capacity is not a service instruction; use matched literature for the correct oil and procedure.
Type
Capacity
Fluids, Battery, and Service Facts
Published capacities include 13 gal (49.2 L) of fuel, 5 qt (4.7 L) of engine oil, and 15 qt (14.2 L) of coolant. Confirm the actual engine and tractor before using a manual for servicing details.
Fuel tank
Engine oil capacity
Hydraulic system
Battery volts
Battery Ah
Tires and Dimensions
Tire and dimension values can vary by wheel, axle, and configuration.
Wheelbase
Weight
Length
Height
Ag front
Ag rear
Electrical
Published electrical entries list a positive 6-volt ground system with a generator and 20-amp charging output. Check the tractor's installed system before replacing electrical components.
Ground
Charging system
Charging amps
Battery volts
Serial Number Lookup
The serial-number plate is listed on the left side behind the starter, on top of the transmission case. Treat the year rows as identification aids and compare the full tag before relying on one.
1957
1958
1959
1960
1961
1962
location
Manuals and Documents
The linked service-manual listing is for the 1958-1962 Ford 771. The linked illustrated parts-manual listing states gas, LP, and diesel applications. Both are literature routes, not proof that an unseen procedure or part fits every tractor.
Before using either reference, record the serial number, engine, transmission, PTO setup, and electrical system from the tractor itself.
Service manual
- Ford 771 service manualoperation, maintenance, and specifications
Commercial service-manual listing for 1958-1962 Ford 771 tractors. Confirm the actual tractor before use.
View service manual
Parts catalog
- Ford 771 parts manualparts matching
Commercial 858-page parts-manual listing for stated gas, LP, and diesel applications. Verify fitment before ordering.
View parts manual
Parts Checks Before Ordering
Start with the serial number, then confirm the engine, Select-O-Speed transmission, PTO equipment, hitch, and electrical system. A parts catalog helps identify assemblies but does not prove fitment for an individual 771.
Keep the model tag and any casting or component numbers with the order. That matters especially where a catalog lists more than one engine or fuel application.
- Ford 771 parts manualCommercial 858-page illustrated-parts-manual listing for stated gas, LP, and diesel applications. Verify the serial number and configuration before ordering.View parts manual
Accuracy Note
Tractor specifications can vary by year, region, factory configuration, installed equipment, and later repairs. Match serial range, engine, transmission, PTO setup, and model code before ordering parts or doing service work.
