New Holland 4835 Overview
The New Holland 4835 was produced from 1996 to 1999 with a 220 ci (3.6 L) engine listed at 65 hp (48.5 kW) and 2,500 rpm. It has a 29 gal (109.8 L) fuel tank, independent 540 rear PTO, and a Type II hitch listed with 5,722 lb lift at 24 inches. The open-center hydraulic system is listed at 14.5 gpm pump flow. Published shipping weights range from 5,954 lb for a 2WD ROPS tractor to 7,056 lb for a 4WD cab tractor.
New Holland 4835 Quick Answers
- YearsNew Holland produced the 4835 from 1996 through 1999.
- EngineIts 220 ci (3.6 L) engine is listed at 65 hp and 2,500 rpm.
- Rear hitchThe Type II hitch is listed with 5,722 lb lift at 24 inches.
- Fuel capacityThe fuel tank is listed at 29 gal (109.8 L).
Engine and Power
The 220 ci (3.6 L) engine is listed at 65 hp and 2,500 rpm.
Diesel engine
| Displacement | 220 ci 3.6 L |
|---|---|
| Rated Rpm | 2500 |
| Engine Oil Capacity | 12.4 qts 11.7 L |
| Coolant Capacity | 14.8 qts (ROPS) 14.0 L |
Manufacturer
Manufacture years
Engine
PTO and Hitch
The independent rear PTO is listed at 540, with a Type II hitch and 5,722 lb lift at 24 inches.
Rear PTO
Rear PTO type
Rear hitch
Rear lift at 24 inches
Hydraulics
The open-center hydraulic system is listed with 14.5 gpm pump flow.
Type
Pump flow
Accuracy Note
Tractor specifications can vary by year, region, factory configuration, installed equipment, and later repairs. Match serial range, engine, transmission, PTO setup, and model code before ordering parts or doing service work.
