CaseIH 585 Overview
Built from 1985 to 1990, the CaseIH 585 uses a 206 ci (3.4 L) diesel engine rated at 60 hp and 2300 rpm. Its independent 540/1000 PTO, open-center hydraulics with a 15.1 gpm pump, and II/I rear hitch suit it to a range of implement work. Fuel capacity is 20 gal, while listed weight spans 5640 to 6765 pounds. The serial sequence begins at 15000 for 1985 and progresses through the model run.
CaseIH 585 Quick Answers
- YearsProduced from 1985 through 1990.
- Engine206 ci (3.4 L) diesel rated at 60 hp and 2300 rpm.
- Rear PTOIndependent PTO with 540/1000 speeds.
- HydraulicsOpen-center system with 15.1 gpm pump flow.
Engine and Power
The 206 ci diesel engine is rated at 2300 rpm.
Diesel engine
| Displacement | 206 ci 3.4 L |
|---|---|
| Rated Rpm | 2300 |
Manufacture years
Engine
PTO and Hitch
An independent 540/1000 rear PTO accompanies the II/I rear hitch.
Rear PTO
Rear PTO type
Rear hitch
Hydraulics
Open-center hydraulics use a 15.1 gpm pump and a 9 gal system capacity.
Type
Capacity
Pump flow
Fluids, Battery, and Service Facts
The 20 gal fuel capacity and 9 gal hydraulic system are useful service references.
Fuel tank
Hydraulic system
Accuracy Note
Tractor specifications can vary by year, region, factory configuration, installed equipment, and later repairs. Match serial range, engine, transmission, PTO setup, and model code before ordering parts or doing service work.
