Ford 8000 Overview
Built from 1968 through 1972, the Ford 8000 is listed with a 401 cu in (6.6 L) six-cylinder diesel engine. The published transmission record identifies the 16-forward, 4-reverse Dual Power version, but configuration matters: the University of Nebraska records a standard Ford 8000 diesel separately from a Ford 8000 diesel Dual Power.
The page keeps the independent-test records attached to their exact configurations rather than turning a result from one test tractor into a universal 8000 claim. That distinction also matters when comparing transmission, PTO, hydraulic, or parts information.
Operator and parts-manual routes are collected below for practical research. Match the tractor's serial number, installed transmission, PTO equipment, and chassis before using a procedure or ordering a part.
Ford 8000 Quick Answers
- What engine is in a Ford 8000?The Ford 8000 is listed with a 401 cu in (6.6 L) six-cylinder diesel rated at 2,300 rpm. The published engine listing gives 115.5 hp (86.1 kW).
- What transmission is listed for the Ford 8000?The published Ford 8000 transmission listing is Dual Power, a two-speed power-shift arrangement with 16 forward and 4 reverse gears. Confirm the actual transmission before using its specifications or buying parts.
- What PTO does a Ford 8000 use?The Ford 8000 is listed with an independent rear PTO and 540/1000-rpm PTO speeds. The published 540-rpm setting is 1,900 engine rpm; confirm the shaft and equipment on the tractor before matching an implement.
- What are the listed Ford 8000 fluid capacities?Published listings give a 43 gal (162.8 L) fuel capacity, 12 qt (11.4 L) engine-oil capacity, and 18 qt (17.0 L) coolant capacity. Use matching literature for fluid grades, intervals, and fill procedures.
- Are there Nebraska tests for the Ford 8000?Yes. Nebraska Test 973 is for a Ford 8000 diesel, while Test 1026 is for a Ford 8000 diesel Dual Power, also labelled a Dual Power row-crop version. Keep each report with its exact tested configuration.
- Which manuals are useful for a Ford 8000?The literature links below include a 74-page operator-manual listing for Ford 8000 row-crop and all-purpose tractors and a multi-model 8000-series parts catalog. They are research routes, so use the tractor's serial number and installed equipment for the final match.
Engine and Power
The Ford 8000 is listed with a 401 cu in (6.6 L) six-cylinder diesel, rated at 2,300 rpm. Its published 115.5 hp figure is an engine listing; use the separately labelled Nebraska reports for configuration-specific test context.
Diesel engine
| Displacement | 401 ci 6.6 L |
|---|---|
| Power | 115.5 hp 86.1 kW |
| Compression | 16.5:1 |
| Rated Rpm | 2300 |
| Coolant Capacity | 18 qts 17.0 L |
Manufacture years
Transmission
The published listing identifies a 16F/4R Dual Power two-speed power-shift transmission. Nebraska recorded the standard diesel Ford 8000 and the diesel Dual Power tractor separately, which is why a test result or parts listing must stay tied to the installed drivetrain.
Dual Power
| Name | Dual Power |
|---|---|
| Type | two-speed power shift |
| Gears | 16 forward and 4 reverse |
PTO and Hitch
The Ford 8000 is listed with an independent rear PTO and 540/1000-rpm PTO speeds, with 540 rpm at 1,900 engine rpm. Confirm the actual PTO shaft and equipment before implement setup.
Rear PTO
Rear PTO type
Engine RPM
Rear hitch
Hydraulics
Published specifications list open-center hydraulics with 12 gpm (45.4 L/min) pump flow. Remotes, steering equipment, and condition can differ, so the tractor itself remains the final check for hydraulic work or parts.
Type
Pressure
Pump flow
Fluids, Battery, and Service Facts
Published capacities include 43 gal (162.8 L) of fuel, 12 qt (11.4 L) of engine oil, and 18 qt (17.0 L) of coolant. A capacity is not a service procedure: use configuration-matched operator literature for specifications, grades, intervals, and safe filling steps.
Fuel tank
Engine oil capacity
Tires and Dimensions
Tire and dimension values can vary by wheel, axle, and configuration.
Wheelbase
Length
Manuals, Parts, and Nebraska Tests
The University of Nebraska publishes two exact Ford 8000 records: Test 973 for the Ford 8000 diesel and Test 1026 for the Ford 8000 diesel Dual Power. They are useful independent documents, but their results belong to their respective test tractors rather than every 8000.
The operator-manual and parts-catalog listings below are literature-access routes. Match the serial number, all-purpose or row-crop chassis, transmission, PTO, and installed equipment before relying on a procedure or a part reference.
Tractor test report
- Nebraska Test 973: Ford 8000 Dieseltested performance
Official May 1968 record for the tested Ford 8000 diesel configuration.
Open Test 973 record - Nebraska Test 1026: Ford 8000 Diesel Dual Powertested performance
Official October 1969 record for the tested Ford 8000 diesel Dual Power configuration.
Open Test 1026 record
Operator manual
- Ford 8000 operator manualoperation, maintenance, and specifications
Commercial 74-page operator-manual listing for row-crop and all-purpose tractors. Match serial number and configuration before use.
View operator manual
Parts catalog
- Ford 8000-series parts catalogparts matching
Commercial multi-model catalog with parts names, numbers, and exploded views. Confirm exact 8000 fitment before ordering.
View parts catalog
Parts Checks Before Ordering
Use the tractor's serial number first, then confirm whether it is the standard or Dual Power configuration, the chassis type, PTO equipment, and the installed hydraulic and wheel equipment. A model name alone is not a complete parts match.
The multi-model parts catalog is a useful assembly-reference route, not proof that a part fits every Ford 8000. Verify exact fitment in matching literature and against the tractor before ordering.
- Ford 8000-series parts catalogCommercial 608-page parts-catalog listing for Ford 8000, 8200, 8400, 8600, and 8700 tractors. It includes parts names, numbers, and exploded views; confirm the exact tractor before ordering.View parts catalog
Accuracy Note
Tractor specifications can vary by year, region, factory configuration, installed equipment, and later repairs. Match serial range, engine, transmission, PTO setup, and model code before ordering parts or doing service work.
